Ball Transfer Units - 6 Inch Ball Centers

FOB: Our Arkansas Warehouse

$75.00 Minimum Order
"X" at end of model number = Length

Enhance your conveyor systems with Roach Ball Transfer Units, featuring 6" ball centers for seamless material handling. These assemblies include 1" diameter steel balls housed in durable 1-13/16" diameter casings, ensuring smooth and precise movement. With a ball capacity of 50 lbs each and a max unit load of 200 lbs (supported by 4 balls), these units are perfect for various industrial applications.

Built to last, the 3-1/2" x 1-1/2" x 10-gauge steel frame provides exceptional durability, supporting up to 1300 lbs of distributed load on a 10' section with supports at 10' centers or 3200 lbs at 5' centers. Balls are set high for effortless transfer, sitting 1/4" above side frames for optimal function. Available with plates crafted from 10-gauge steel for widths up to 39" and 7-gauge steel for wider sizes, these units are designed to handle tough jobs.

Designed for industrial efficiency, Roach Ball Transfer Units offer a seamless solution for transferring and handling packages in demanding environments. Maximize your workflow with Material Flow's premium offerings today!

• Ball Diameter: 1"
• Housing Diameter: 1-13/16"
• Ball Capacity: 50 lbs per ball (200 lbs max for 4 balls)
• Frame Dimensions: 3-1/2" x 1-1/2" x 10 gauge steel
• Frame Capacity: 1300 lbs max at 10' supports; 3200 lbs at 5' centers
• Ball Centers: 6"
• Plates: 10-gauge steel up to 39"; 7-gauge for above 39"
• Mounting Bolt: 1/4"-20
• Ball Spacing: Minimum package dimension ÷ 2.5
