Teardrop 5 x 120 Storage Rack Beams

FOB: Oregon Warehouse

Stocked Color - Orange

Upgrade your warehouse storage with Teardrop 5" x 120" Storage Rack Beams in Material Flow's stocked orange color. Engineered for maximum strength and universal teardrop compatibility, these beams are built from high-grade steel and feature a 2” vertical adjustment step beam design. They accommodate crossbars, wood stringers, or wire decking, giving you versatile storage options.

Each beam is equipped with removable safety load clips to enhance security and ensure stability in your racking system. Seismic-rated 5” x 7” x 3/8” plates come standard, making these beams ideal for high-capacity industrial applications.

Looking for a customized racking solution? We offer custom height and depth frames, as well as reinforced struts, columns, and frame designs tailored to your operation’s needs. Plus, our quick-ship program ensures fast delivery on the most common sizes. Get the best in warehouse storage solutions—order your Teardrop 5" x 120" Storage Rack Beams today!

Volume Discounts Available:

• 1,000 - 2,999 → Save 5%
• 3,000 - 4,999 → Save 7%
• 5,000 - 9,999 → Save 10%
• 10,000+ → Contact us for pricing!

Combine beams and frames for even bigger savings!

• Beam Type: Teardrop Storage Rack Beam
• Dimensions: 5" x 120"
• Material: High-grade steel
• Adjustment: 2" vertical centers
• Color: Material Flow Stocked Orange
• Seismic Plates: 5" x 7" x 3/8" (Standard)
• Compatibility: Interchanges with most teardrop designs
• Accessories: Supports crossbars, wood stringers, wire decking
• Safety Features: Removable safety load clips on each end
• Note: Upright frame capacities are based on 42" maximum vertical beam spacing.

How to Choose the Right Pallet Rack

Frame Capacity

• Calculate the total weight of all pallets stored in a bay (excluding floor-level pallets). Ensure the frame can handle the combined load.

Height

• Measure the full vertical space, including pallet height, pallet load, and beam height.
• Add 4 inches of clearance between the top of the load and the beam above.
• The top beam should be at least 6 inches below your forklift's maximum lifting height.

Depth

• Pallets should overhang the frame by 3 inches on the front and back.
• Example: A 48-inch pallet requires a 42-inch deep frame (deduct 6 inches from the pallet depth).
• Ensure pallets are in good condition for stability and safety.

Width

• Measure the width of the pallet and add:
  • • 3 inches of clearance between the pallet and frame.
    • 4 inches of space between adjacent pallets.
• Choose beams that support the total pallet weight per level.
• Add-on sections need only one additional frame and the required number of beams.

We don’t just sell racks—we provide tailored solutions to fit your operation!
