Teardrop 3 x 60 Storage Rack Beams

FOB: Oregon Warehouse

Stocked Color - Orange

Maximize your storage efficiency with these versatile Teardrop 3 x 60 Storage Rack Beams. Engineered to work with most teardrop designs, they are constructed from high-grade steel for durability. The beams offer 2" vertical adjustment steps, support crossbars, wood stringers, or wire decking, and come with safety load clips for secure assembly. Perfect for seismic safety, they include 5"x7"x3/8" plates and are available in custom heights and depths. Combine with frames for volume discounts and faster shipping.

• Vertical adjustment: 2" centers
• Seismic plates: 5" x 7" x 3/8"
• Custom height and depth options
• Volume discounts on bulk orders
• Note: Upright frame capacities are based on 42" maximum vertical beam spacing.

Volume Discounts:

• Orders of 1,000 – 2,999 units: Save 5%
• Orders of 3,000 – 4,999 units: Save 7%
• Orders of 5,000 – 9,999 units: Save 10%
• Orders of 10,000+ units: Contact us for pricing

How to Select Pallet Rack:

1. Frame Capacity
   Calculate the total weight of all pallets stored in each bay, excluding those on the floor.

2. Height
   Measure the height of the pallet, load, and beams. Ensure 4" clearance between the top of the load and the beam above. The top beam should be 6" lower than the forklift’s maximum lift height.

3. Depth
   Pallets should overhang the frame by 3" front and back. Use a frame that’s 6" less than the pallet depth.

4. Width
   Measure pallet width, then add 3" for pallet-to-frame clearance and 4" between pallets. Each beam pair must support the weight of pallets per level. Add-on sections require one extra frame and the necessary beams.

This approach ensures your racking system fits your specific storage needs, rather than just offering a standard solution.
