STP6900 Series Heavy Duty Swivel Casters
Write a Review
Material Flow
STP6900 Series Heavy Duty Swivel Casters
- SKU:
- STP6900 Series Heavy Duty Swivel Casters
- UPC:
- Condition:
- New
FOB: Oregon Warehouse
Lead time: 2-5 days
Conquer tough industrial jobs with Material Flow’s STP6900 Series Heavy Duty Swivel Casters. Built for intense applications like cargo containers and freight terminal trucks, these casters are engineered for strength and smooth maneuverability.
With bright zinc plating for durability and a double ball bearing swivel with hardened raceways, you get unmatched swivel action and load support. The large top plate and reinforced fork spacing ensure rock-solid stability, while Zerk grease fittings in the swivel section make maintenance effortless. Ideal for carts, platform trucks, and high-impact environments.
-
Finish: Bright zinc plating
-
Swivel: Double ball bearing with hardened raceways
-
Fork Spacing: 3"
-
Top Plate: Oversized with heavy-duty raceway
-
Kingpin: 3/4" diameter bolt and nut
-
Leg Thickness: 23/64"
-
Axle: 3/4" diameter with lock nut
-
Grease Fittings: Zerk in swivel section
-
Applications: Cargo containers, freight terminal trucks, material handling carts, large platform trucks
-
Additional Info: Surcharges may apply
| Model No. | Model No. | Fastening Type | Fastening Size | Overall Height | Wheel Diameter | Wheel Type | Wheel Bearing | Load Capacity | Swivel Radius | Tread Width | Price | Qty |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 79353 | STP6980-HD-PCI | Top Plate | 4-1/2" x 6-1/4" | 9-3/4" | 8" | Polyurethane / Cast Iron | Roller | 1600 lbs. | 6-1/4" | 2-1/2" |
$75.07
|
|
| 79469 | STP6960-HD-RCI | Top Plate | 4-1/2" x 6-1/4" | 7-1/2" | 6" | Rubber / Cast Iron | Roller | 700 lbs. | 4-3/4" | 2-1/2" |
$56.07
|
|
| 79695 | STP6910-HD-PCI | Top Plate | 4-1/2" x 6-1/4" | 11-1/2" | 10" | Polyurethane / Cast Iron | Roller | 1800 lbs. | 7-3/8" | 2-1/2" |
$81.07
|
|
| 79793 | STP6980-HD-PHN | Top Plate | 4-1/2" x 6-1/4" | 9-3/4" | 8" | Phenolic | Roller | 1600 lbs. | 6-1/4" | 2-1/2" |
$68.07
|
|
| 79831 | STP6910-HD-SDI | Top Plate | 4-1/2" x 6-1/4" | 11-1/2" | 10" | Ductile Iron | Roller | 2000 lbs. | 7-3/8" | 2-1/2" |
$119.07
|
|
| 79853 | STP6960-HD-PCI | Top Plate | 4-1/2" x 6-1/4" | 7-1/2" | 6" | Polyurethane / Cast Iron | Roller | 1500 lbs. | 4-3/4" | 2-1/2" |
$66.07
|
|
| 79873 | STP6960-HD-STL | Top Plate | 4-1/2" x 6-1/4" | 7-1/2" | 6" | Steel | Roller | 1500 lbs. | 4-3/4" | 2-1/2" |
$62.07
|
|
| 80094 | STP6910-HD-PHN | Top Plate | 4-1/2" x 6-1/4" | 11-1/2" | 10" | Phenolic | Roller | 1800 lbs. | 7-3/8" | 2-1/2" |
$70.07
|
|
| 80248 | STP6980-HD-RCI | Top Plate | 4-1/2" x 6-1/4" | 9-3/4" | 8" | Rubber / Cast Iron | Roller | 850 lbs. | 6-1/4" | 2-1/2" |
$63.07
|
|
| 80317 | STP6960-HD-SDI | Top Plate | 4-1/2" x 6-1/4" | 7-1/2" | 6" | Ductile Iron | Roller | 1800 lbs. | 4-3/4" | 2-1/2" |
$85.07
|
|
| 80389 | STP6960-HD-PHN | Top Plate | 4-1/2" x 6-1/4" | 7-1/2" | 6" | Phenolic | Roller | 1500 lbs. | 4-3/4" | 2-1/2" |
$64.06
|
|
| 80509 | STP6910-HD-RCI | Top Plate | 4-1/2" x 6-1/4" | 11-1/2" | 10" | Rubber / Cast Iron | Roller | 950 lbs. | 7-3/8" | 2-1/2" |
$79.07
|
|
| 80676 | STP6980-HD-SDI | Top Plate | 4-1/2" x 6-1/4" | 9-3/4" | 8" | Ductile Iron | Roller | 2000 lbs. | 6-1/4" | 2-1/2" |
$90.07
|
|
| 80968 | STP6910-HD-STL | Top Plate | 4-1/2" x 6-1/4" | 11-1/2" | 10" | Steel | Roller | 1800 lbs. | 7-3/8" | 2-1/2" |
$86.07
|
