Payson MEDIUM HEAVY-DUTY CASTERS

Medium Heavy-Duty Casters

Manufacturer: Payson Casters
$18.81
(No reviews yet) Write a Review
Condition:
New

FOB: Our Illinois Warehouse

Handle tough jobs with ease using Payson Medium Heavy Duty Casters, proudly made in the USA and available at Material Flow. Built from rugged cold-forged steel, these casters are engineered with two large-diameter ball bearing raceways for smooth swivel action under heavy loads.

The zinc-plated finish ensures durability, while built-in lubrication fittings simplify maintenance for long service life. A 5/8" nut and bolt kingpin, precision roller bearing, and reinforced raceways give these casters the strength to thrive in demanding industrial applications.

Choose from multiple wheel options to match your specific needs: Payron (cast iron steel) for extreme durability, Plexite (black phenolic) for lightweight strength, or Payvulc (black mold-on rubber) for quieter operation and floor protection.

(Steel surcharge may apply.)

  • Brand: Payson Casters

  • Product: Medium Heavy Duty Casters

  • Origin: Made in USA

  • Construction: Cold-forged steel, zinc plated

  • Raceways:

    • Two separate large-diameter ball bearing raceways

    • Upper and lower raceways: 1/4"

  • Bearings: Roller bearing, 5/16" load balls, 1/4" lower raceway balls

  • Kingpin: 5/8" nut and bolt

  • Top Plate:

    • Thickness: 1/4" cold forged

    • Dimensions: 4" x 4-1/2"

    • Bolt Hole Pattern: 2-5/8" x 3-5/8", slotted to 3" x 3"

  • Features: Lubrication fittings for extended life

  • Wheel Options:

    • Payron: Cast iron steel

    • Plexite: Black phenolic

    • Payvulc: Black mold-on rubber

  • Steel surcharge: May apply

Model No. Model No. Style Diameter Width Capacity Type Weight Overall Height Price Qty
58457 190-4UM Swivel 4" 2" 500 lbs Plexite 5 lbs 5-5/8"
$36.49
58799 190-6US Swivel 6" 2" 850 lbs Payron 9 lbs 7-1/2"
$50.75
58987 190-5UM Swivel 5" 2" 700 lbs Plexite 5-1/2 lbs 6-1/2"
$34.55
59071 190-4UP Swivel 4" 2" 325 lbs Payvulc 5 lbs 5-5/8"
$22.91
59073 190-4US Swivel 4" 2" 550 lbs Payron 6-1/2 lbs 5-5/8"
$42.16
59540 190-6UM Swivel 6" 2" 820 lbs Plexite 7 lbs 7-1/2"
$32.16
59559 190-8US Swivel 8" 2" 1050 lbs Payron 12-1/2 lbs 9-1/2"
$61.12
59582 190-5UP Swivel 5" 2" 375 lbs Payvulc 5-1/2 lbs 6-1/2"
$26.34
59757 190-5US Swivel 5" 2" 700 lbs Payron 7-1/2 lbs 6-1/2"
$47.84
60082 190-6UP Swivel 6" 2" 410 lbs Payvulc 7 lbs 7-1/2"
$29.40
60193 191-4UM Rigid 4" 2" 500 lbs Plexite 5 lbs 5-5/8"
$28.06
60239 190-8UM Swivel 8" 2" 1000 lbs Plexite 8-1/2 lbs 9-1/2"
$39.10
60574 191-5UP Rigid 5" 2" 375 lbs Payvulc 5-1/2 lbs 6-1/2"
$23.73
60587 191-4UP Rigid 4" 2" 325 lbs Payvulc 5 lbs 5-5/8"
$18.81
60759 190-8UP Swivel 8" 2" 500 lbs Payvulc 8-1/2 lbs 9-1/2"
$38.66
61108 191-5US Rigid 5" 2" 700 lbs Payron 7-1/2 lbs 6-1/2"
$45.52
61172 191-4US Rigid 4" 2" 550 lbs Payron 6-1/2 lbs 5-5/8"
$37.46
61306 191-6US Rigid 6" 2" 850 lbs Payron 9 lbs 7-1/2"
$47.39
61321 191-8US Rigid 8" 2" 1050 lbs Payron 12-1/2 lbs 9-1/2"
$50.15
61411 191-5UM Rigid 5" 2" 700 lbs Plexite 5-1/2 lbs 6-1/2"
$28.88
61839 191-8UM Rigid 8" 2" 1000 lbs Plexite 8-1/2 lbs 9-1/2"
$37.24
61953 191-6UM Rigid 6" 2" 820 lbs Plexite 7 lbs 7-1/2"
$30.30
62261 191-8UP Rigid 8" 2" 500 lbs Payvulc 8-1/2 lbs 9-1/2"
$33.36
62353 191-6UP Rigid 6" 2" 410 lbs Payvulc 7 lbs 7-1/2"
$27.39
!
